Featured Products | Connectivity Kits | WS709

High-Performance Connectivity with the Whizz Virtex-7 FPGA WS709

Customizable High-Bandwidth Platform Built for Next-Gen Applications

The WS709 – A Customizable Derivative of Xilinx’s VC709 Connectivity Kit

Product Overview

The WS709 – A Customizable Derivative of Xilinx’s VC709 Connectivity Kit

The Whizz Virtex-7 FPGA WS709 is a high-speed 40Gb/s connectivity platform designed for high-bandwidth and high-performance applications. As a derivative of the AMD Virtex™ 7 FPGA VC709 Connectivity Kit, the WS709 retains all the advanced features while supporting the XC7VX2000T FPGA.

With PCI Express Gen 3, 10GBase-R, AXI, and DDR3 memory interfacing, this platform enables rapid evaluation and development of networking, high-speed computing, and data transfer applications. The included Fedora Live OS-based GUI, along with software drivers, allows for efficient control and monitoring of connectivity designs.

Whizz Systems offers full customization services to tailor this platform to your specific application needs.

Divider

Whizz Systems specialize in transforming development kits into fully productized, market-ready solutions for a wide range of industries

Divider

Key Features & Benefits

Engineered for High-Speed Connectivity & Scalable Customization


FPGA – Virtex-7 VX690T (XC7VX2000T)


Memory – 2 x 4GB DDR3 SODIMM (933MHz / 1866Mbps), 32MB BPI Parallel NOR Flash, 1KB IIC EEPROM


PCIe – Gen3 8-lane edge connector


Clocking 200MHz fixed oscillator, 233.33MHz fixed oscillator, User Programmable Oscillator, SMA clock inputs


Networking – 4x SFP/SFP+ cages, 10x GTH ports to FMC, UART to USB Bridge


Configuration – JTAG over USB, BPI Parallel NOR Flash


Expansion – FMC-HPC, GTH transceivers


Control I/O– Push buttons, DIP switches, User LEDs


Power – 12V AC adapter or ATX


Customization Options

Productize Your Development Kit for Your Applications

Whizz Systems specializes in transforming FPGA evaluation kits into deployable, market-ready solutions. Our expertise in AMD Xilinx FPGA platforms enables us to optimize your WH705 kit for real-world applications with enhanced performance and custom features..

undefined

Productizing Development Kits

Turn the WS709 into a deployable product with optimized hardware and software.

undefined

Complete System Development

Create an end-to-end system including enclosures, firmware, and thermal solutions.

undefined

FPGA Modifications

Upgrade or modify the FPGA for specialized processing applications.

undefined

Memory Enhancements

Expand DDR3/DDR4 configurations based on performance needs.

undefined

Custom Connectivity

Modify PCIe lanes, add additional SFP/SFP+ ports, or adjust I/O configurations.

undefined

Software & Firmware Customization

Develop specialized drivers, GUI, or firmware.

undefined

Power & Thermal Optimization

Enhance power delivery and cooling mechanisms.

Trusted Expertise, Backed by Collaboration

Trusted Expertise, Backed by Collaboration

Leverage Our Proven Industry Partnerships for Your Product

When you work with Whizz Systems, you gain access to a trusted partner with deep expertise in AMD Xilinx FPGA platforms. Our 25 years experience of servicing AMD/Xilinx in developing reference designs, evaluation kits, and connectivity solutions allows us to bring industry-leading experience to your project.

We understand the architecture, design methodologies, and best practices used in AMD Xilinx-based solutions because we’ve worked directly with them. Now, we’re extending that expertise to you—whether you need custom FPGA solutions, modifications to existing development kits, or full productization of your design.

Looking to Productize Your Dev Kit? Let’s Build It Together!
